SKF 81217 TN
Bearing Specifications
| d(mm) | D(mm) | B(mm) | Cr(kN) | Cor(kN) |
| 85 | 125 | 31 | 170 | 640 |
[xyz-ihs snippet=”table-css”][xyz-ihs snippet=”share-to-media”]
Product Description
[xyz-ihs snippet=”Product-detail”]
[xyz-ihs snippet=”Product-feature”]
[xyz-ihs snippet=”pic”]
[xyz-ihs snippet=”FAQ”]
| Model | Inner d (mm) | Outer D (mm) | Width B (mm) | Action |
|---|---|---|---|---|
| 81206 | 30 | 52 | 16 | |
| 81206 TN | 30 | 52 | 16 | |
| 81207 | 35 | 62 | 18 | |
| 81207 TN | 35 | 62 | 18 | |
| 81208 | 40 | 68 | 19 | |
| 81208 TN | 40 | 68 | 19 | |
| 81209 | 45 | 73 | 20 | |
| 81209 TN | 45 | 73 | 20 | |
| 81210 | 50 | 78 | 22 | |
| 81210 TN | 50 | 78 | 22 | |
| 81211 | 55 | 90 | 25 | |
| 812111 | 55 | 90 | 25 | |
| 81211 TN | 55 | 90 | 25 | |
| 81212 | 60 | 95 | 26 | |
| 81212 TN | 60 | 95 | 26 | |
| 81213 | 65 | 100 | 27 | |
| 81213 TN | 65 | 100 | 27 | |
| 81214 | 70 | 105 | 27 | |
| 81214 TN | 70 | 105 | 27 | |
| 81215 | 75 | 110 | 27 | |
| 81215 TN | 75 | 110 | 27 | |
| 81216 | 80 | 115 | 28 | |
| 81216 TN | 80 | 115 | 28 | |
| 81217 | 85 | 125 | 31 | |
| 81217 TN | 85 | 125 | 31 | |
| 81218 | 90 | 135 | 35 | |
| 81218 TN | 90 | 135 | 35 | |
| 81220 | 100 | 150 | 38 | |
| 81220 TN | 100 | 150 | 38 | |
| 81222 | 110 | 160 | 38 | |
| 81222 TN | 110 | 160 | 38 | |
| 81224 | 120 | 170 | 39 | |
| 81224 TN | 120 | 170 | 39 | |
| 81226 | 130 | 190 | 45 | |
| 81226 TN | 130 | 190 | 45 | |
| 81228 | 140 | 200 | 46 | |
| 81228 M | 140 | 200 | 46 | |
| 81230 | 150 | 215 | 50 | |
| 81230 M | 150 | 215 | 50 | |
| 81232 | 160 | 225 | 51 | |
| 81232 M | 160 | 225 | 51 | |
| 81234 | 170 | 240 | 55 | |
| 81234 M | 170 | 240 | 55 | |
| 81236 | 180 | 250 | 56 | |
| 81236 M | 180 | 250 | 56 | |
| 81238 | 190 | 270 | 62 | |
| 81238 M | 190 | 270 | 62 | |
| 81240 | 200 | 280 | 62 | |
| 81240 M | 200 | 280 | 62 | |
| 81244 | 220 | 300 | 63 | |
| 81244 M | 220 | 300 | 63 | |
| 81248 | 240 | 340 | 78 | |
| 81248 M | 240 | 340 | 78 | |
| 81252 | 260 | 360 | 79 | |
| 81252 M | 260 | 360 | 79 | |
| 81256 | 280 | 380 | 80 | |
| 81256 M | 280 | 380 | 80 | |
| 81260 | 300 | 420 | 95 | |
| 81260 M | 300 | 420 | 95 | |
| 81264 | 320 | 440 | 95 | |
| 81264 M | 320 | 440 | 95 | |
| 81268 | 340 | 460 | 96 | |
| 81268 M | 340 | 460 | 96 | |
| 81272 | 360 | 500 | 110 | |
| 81272 M | 360 | 500 | 110 | |
| 81276 | 380 | 520 | 112 | |
| 81276 M | 380 | 520 | 112 | |
| 81280 | 400 | 540 | 112 | |
| 81280 M | 400 | 540 | 112 | |
| 81284 | 420 | 580 | 130 | |
| 81284 M | 420 | 580 | 130 | |
| 81288 | 440 | 600 | 130 | |
| 81288 M | 440 | 600 | 130 | |
| 81292 | 460 | 620 | 130 | |
| 81292 M | 460 | 620 | 130 | |
| 81296 | 480 | 650 | 135 | |
| 81296 M | 480 | 650 | 135 | |
| 812/500 | 500 | 670 | 135 | |
| 812/500 M | 500 | 670 | 135 | |
| 812/530 | 530 | 710 | 140 | |
| 812/530 M | 530 | 710 | 140 | |
| 812/560 | 560 | 750 | 150 | |
| 812/560 M | 560 | 750 | 150 | |
| 812/600 | 600 | 800 | 160 | |
| 812/600 M | 600 | 800 | 160 | |
| 812/630 M | 630 | 850 | 175 | |
| 812/670 M | 670 | 900 | 180 | |
| 812/710 M | 710 | 950 | 190 | |
| 812/750 M | 750 | 1000 | 195 | |
| 812/800 M | 800 | 1060 | 205 | |
| 812/850 M | 850 | 1120 | 212 | |
| 812/900 M | 900 | 1180 | 220 | |
| 812/950 M | 950 | 1250 | 236 | |
| 812/1000 M | 1000 | 1320 | 250 | |
| 812/1060 M | 1060 | 1400 | 265 |
* The above dimensions are standard specifications. Please confirm actual dimensions before ordering.
