Double direction flat series
Double direction thrust ball bearing
Double direction thrust ball bearings can accommodate axial loads in both directions, but they must not be subjected to any radial load. Their separable components facilitate mounting/dismounting and maintenance inspections…
Product Description
\n
\nProduct Details
\n
\nDouble direction thrust ball bearing
\nDouble direction thrust ball bearings can accommodate axial loads in both directions, but they must not be subjected to any radial load. Their separable components facilitate mounting/dismounting and maintenance inspections, and many of the components are interchangeable. The shaft washers have a ground bore that enables an interference fit.
\nSeparable design facilitates mounting/dismounting and maintenance inspections
\nInterchangeable components
\nGround bore of the shaft washers enables interference fits
\n
\n
\n
\nDetailed pictures
\n
\n
\n
\n
\n
\nParameter table
\n
\nProduct Details
\n
\nDouble direction thrust ball bearing
\nDouble direction thrust ball bearings can accommodate axial loads in both directions, but they must not be subjected to any radial load. Their separable components facilitate mounting/dismounting and maintenance inspections, and many of the components are interchangeable. The shaft washers have a ground bore that enables an interference fit.
\nSeparable design facilitates mounting/dismounting and maintenance inspections
\nInterchangeable components
\nGround bore of the shaft washers enables interference fits
\n
\n
\n
\nDetailed pictures
\n
\n
\n
\n
\n
\nParameter table
\n
| Bearing Number | d mm | D mm | H mm |
| 52202 | 10 | 32 | 22 |
| 52204 | 15 | 40 | 26 |
| 52205 | 20 | 47 | 28 |
| 52305 | 20 | 52 | 34 |
| 52406 | 20 | 70 | 52 |
| 52206 | 25 | 52 | 29 |
| 52306 | 25 | 60 | 38 |
| 52407 | 25 | 80 | 59 |
| 52207 | 30 | 62 | 34 |
| 52208 | 30 | 68 | 36 |
| 52307 | 30 | 68 | 44 |
| 52308 | 30 | 78 | 49 |
| 52408 | 30 | 90 | 65 |
| 52209 | 35 | 73 | 37 |
| 52309 | 35 | 85 | 52 |
| 52409 | 35 | 100 | 72 |
| 52210 | 40 | 78 | 39 |
| 52210 | 40 | 78 | 39 |
| 52310 | 40 | 95 | 58 |
| 52211 | 45 | 90 | 45 |
| 52311 | 45 | 105 | 64 |
| 52411 | 45 | 120 | 87 |
| 52212 | 50 | 95 | 46 |
| 52312 | 50 | 110 | 64 |
| 52412 M | 50 | 130 | 93 |
| 52213 | 55 | 100 | 47 |
| 52313 | 55 | 115 | 64 |
| 52314 | 55 | 125 | 72 |
| 52215 | 60 | 110 | 47 |
| 52315 | 60 | 135 | 79 |
| 52216 | 65 | 115 | 48 |
| 52316 | 65 | 140 | 79 |
| 52217 | 70 | 125 | 55 |
| 52218 | 75 | 135 | 62 |
| 52220 | 85 | 150 | 67 |
| 52320 | 85 | 170 | 97 |
| 52222 | 95 | 160 | 67 |
| 52224 | 100 | 170 | 68 |
| 52226 | 110 | 190 | 80 |
| 52228 | 120 | 200 | 81 |
| 52230 M | 130 | 215 | 89 |
| 52232 M | 140 | 225 | 90 |
| 52234 M | 150 | 240 | 97 |
