FAG 81148-M
Bearing Specifications
| d(mm) | D(mm) | B(mm) | Cr(N) | Cor(N) |
| 240 | 300 | 45 | 600000 | 2500000 |
[xyz-ihs snippet=”table-css”][xyz-ihs snippet=”share-to-media”]
Product Description
[xyz-ihs snippet=”Product-detail”]
[xyz-ihs snippet=”Product-feature”]
[xyz-ihs snippet=”pic”]
[xyz-ihs snippet=”FAQ”]
| Model | Inner d (mm) | Outer D (mm) | Width B (mm) | Action |
|---|---|---|---|---|
| 81102 | 15 | 28 | 9 | |
| 81102T2 | 15 | 28 | 9 | |
| 81102 TN | 15 | 28 | 9 | |
| 81103 | 17 | 30 | 9 | |
| 81103T2 | 17 | 30 | 9 | |
| 81103 TN | 17 | 30 | 9 | |
| 81104 | 20 | 35 | 10 | |
| 81104T2 | 20 | 35 | 10 | |
| 81104 TN | 20 | 35 | 10 | |
| 81105 | 25 | 42 | 11 | |
| 81105T2 | 25 | 42 | 11 | |
| 81105 TN | 25 | 42 | 11 | |
| 81106 | 30 | 47 | 11 | |
| 81106T2 | 30 | 47 | 11 | |
| 81106 TN | 30 | 47 | 11 | |
| 81107 | 35 | 52 | 12 | |
| 81107T2 | 35 | 52 | 12 | |
| 81107 TN | 35 | 52 | 12 | |
| 81108 | 40 | 60 | 13 | |
| 81108T2 | 40 | 60 | 13 | |
| 81108 TN | 40 | 60 | 13 | |
| 81109 | 45 | 65 | 14 | |
| 81109T2 | 45 | 65 | 14 | |
| 81109 TN | 45 | 65 | 14 | |
| 81110 | 50 | 70 | 14 | |
| 81110T2 | 50 | 70 | 14 | |
| 81110 TN | 50 | 70 | 14 | |
| 81111 | 55 | 78 | 16 | |
| 81111J | 55 | 78 | 16 | |
| 81111 TN | 55 | 78 | 16 | |
| 81112 | 60 | 85 | 17 | |
| 81112 TN | 60 | 85 | 17 | |
| 81113 | 65 | 90 | 18 | |
| 81113 TN | 65 | 90 | 18 | |
| 81114 | 70 | 95 | 18 | |
| 81114 TN | 70 | 95 | 18 | |
| 81115 | 75 | 100 | 19 | |
| 81115 TN | 75 | 100 | 19 | |
| 81116 | 80 | 105 | 19 | |
| 81116 TN | 80 | 105 | 19 | |
| 81117 | 85 | 110 | 19 | |
| 81117 TN | 85 | 110 | 19 | |
| 81118 | 90 | 120 | 22 | |
| 81118 TN | 90 | 120 | 22 | |
| 81120 | 100 | 135 | 25 | |
| 81120 TN | 100 | 135 | 25 | |
| 81122 | 110 | 145 | 25 | |
| 81122 TN | 110 | 145 | 25 | |
| 81124 | 120 | 155 | 25 | |
| 81124 TN | 120 | 155 | 25 | |
| 81126 | 130 | 170 | 30 | |
| 81126 TN | 130 | 170 | 30 | |
| 81128 | 140 | 180 | 31 | |
| 81128 TN | 140 | 180 | 31 | |
| 81130 | 150 | 190 | 31 | |
| 81130 TN | 150 | 190 | 31 | |
| 81132 | 160 | 200 | 31 | |
| 81132 TN | 160 | 200 | 31 | |
| 81134 | 170 | 215 | 34 | |
| 81134 TN | 170 | 215 | 34 | |
| 81136 | 180 | 225 | 34 | |
| 81136 M | 180 | 225 | 34 | |
| 81138 | 190 | 240 | 37 | |
| 81138 M | 190 | 240 | 37 | |
| 81140 | 200 | 250 | 37 | |
| 81140 M | 200 | 250 | 37 | |
| 81144 | 220 | 270 | 37 | |
| 81144 M | 220 | 270 | 37 | |
| 81148 | 240 | 300 | 45 | |
| 81148 M | 240 | 300 | 45 | |
| 81152 | 260 | 320 | 45 | |
| 81152 M | 260 | 320 | 45 | |
| 81156 | 280 | 350 | 53 | |
| 81156 M | 280 | 350 | 53 | |
| 81160 | 300 | 380 | 62 | |
| 81160 M | 300 | 380 | 62 | |
| 81164 | 320 | 400 | 63 | |
| 81164 M | 320 | 400 | 63 | |
| 81168 | 340 | 420 | 64 | |
| 81168 M | 340 | 420 | 64 | |
| 81172 | 360 | 440 | 65 | |
| 81172 M | 360 | 440 | 65 | |
| 81176 | 380 | 460 | 65 | |
| 81176 M | 380 | 460 | 65 | |
| 81180 | 400 | 480 | 65 | |
| 81180 M | 400 | 480 | 65 | |
| 81184 | 420 | 500 | 65 | |
| 81184 M | 420 | 500 | 65 | |
| 81188 | 440 | 540 | 80 | |
| 81188 M | 440 | 540 | 80 | |
| 81192 | 460 | 560 | 80 | |
| 81192 M | 460 | 560 | 80 | |
| 81196 | 480 | 580 | 80 | |
| 81196 M | 480 | 580 | 80 | |
| 811/500 | 500 | 600 | 80 | |
| 811/500 M | 500 | 600 | 80 | |
| 811/530 | 530 | 640 | 85 | |
| 811/530 M | 530 | 640 | 85 | |
| 811/560 | 560 | 670 | 85 | |
| 811/560 M | 560 | 670 | 85 | |
| 811/600 | 600 | 710 | 85 | |
| 811/600 M/HB1 | 600 | 710 | 85 | |
| 811/630 M | 630 | 750 | 95 | |
| 811/670 M | 670 | 800 | 105 | |
| 811/710 M | 710 | 850 | 112 | |
| 811/750 M | 750 | 900 | 120 | |
| 811/800 M | 800 | 950 | 120 | |
| 811/850 M | 850 | 1000 | 120 | |
| 811/900 M | 900 | 1060 | 130 | |
| 811/950 M | 950 | 1120 | 135 | |
| 811/1000 M | 1000 | 1180 | 140 | |
| 811/1060 M | 1060 | 1250 | 150 | |
| 811/1120 M | 1120 | 1320 | 160 |
* The above dimensions are standard specifications. Please confirm actual dimensions before ordering.
