FAG 89330-M
Bearing Specifications
| d(mm) | D(mm) | B(mm) | Cr(N) | Cor(N) |
| 150 | 250 | 60 | 840000 | 3350000 |
[xyz-ihs snippet=”table-css”][xyz-ihs snippet=”share-to-media”]
Product Description
[xyz-ihs snippet=”Product-detail”]
[xyz-ihs snippet=”Product-feature”]
[xyz-ihs snippet=”pic”]
[xyz-ihs snippet=”FAQ”]
| Model | Inner d (mm) | Outer D (mm) | Width B (mm) | Action |
|---|---|---|---|---|
| 89306 | 30 | 60 | 18 | |
| 89306 TN | 30 | 60 | 18 | |
| 89307 | 35 | 68 | 20 | |
| 89307 TN | 35 | 68 | 20 | |
| 89308 | 40 | 78 | 22 | |
| 89308 TN | 40 | 78 | 22 | |
| 89309 | 45 | 85 | 24 | |
| 89309 TN | 45 | 85 | 24 | |
| 89310 | 50 | 95 | 27 | |
| 89310 TN | 50 | 95 | 27 | |
| 89311 | 55 | 105 | 30 | |
| 89311 TN | 55 | 105 | 30 | |
| 89312 | 60 | 110 | 30 | |
| 89312 TN | 60 | 110 | 30 | |
| 89313 | 65 | 115 | 30 | |
| 89313 TN | 65 | 115 | 30 | |
| 89314 | 70 | 125 | 34 | |
| 89314 TN | 70 | 125 | 34 | |
| 89315 | 75 | 135 | 36 | |
| 89315 TN | 75 | 135 | 36 | |
| 89316 | 80 | 140 | 36 | |
| 89316 TN | 80 | 140 | 36 | |
| 89317 | 85 | 150 | 39 | |
| 89317 M | 85 | 150 | 39 | |
| 89318 | 90 | 155 | 39 | |
| 89318 M | 90 | 155 | 39 | |
| 89320 | 100 | 170 | 42 | |
| 89320 M | 100 | 170 | 42 | |
| 89322 | 110 | 190 | 48 | |
| 89322 M | 110 | 190 | 48 | |
| 89324 | 120 | 210 | 54 | |
| 89324 M | 120 | 210 | 54 | |
| 89326 | 130 | 225 | 58 | |
| 89326 M | 130 | 225 | 58 | |
| 89328 | 140 | 240 | 60 | |
| 89328 M | 140 | 240 | 60 | |
| 89330 | 150 | 250 | 60 | |
| 89330 M | 150 | 250 | 60 |
* The above dimensions are standard specifications. Please confirm actual dimensions before ordering.
