Single direction flat series
Single direction thrust ball bearings can accommodate axial loads in one direction. They must not be subjected to any radial load. Their separable components facilitate mounting/dismounting and maintenance inspections…
Product Description
\nProduct Details
\n
\nSingle direction thrust ball bearing
\nSingle direction thrust ball bearings can accommodate axial loads in one direction. They must not be subjected to any radial load. Their separable components facilitate mounting/dismounting and maintenance inspections. Many of the components are interchangeable. The shaft washers have a ground bore that enables an interference fit.
\nSeparable design facilitates mounting/dismounting and maintenance inspections
\nInterchangeable components
\nGround bore of shaft washers enable interference fit
\n
\n
\n
\nDetailed pictures
\n
\n
\n
\n
\n
\nParameter table
\n
| Bearing Number | d mm | D mm | H mm |
| BA 3 | 3 | 8 | 3.5 |
| BA 4 | 4 | 10 | 4 |
| BA 5 | 5 | 12 | 4 |
| BA 6 | 6 | 14 | 5 |
| BA7 | 7 | 17 | 6 |
| BA 8 | 8 | 19 | 7 |
| BA9 | 9 | 20 | 7 |
| 51100 | 10 | 24 | 9 |
| 51200 | 10 | 26 | 11 |
| 51101 | 12 | 26 | 9 |
| 51201 | 12 | 28 | 11 |
| 51102 | 15 | 28 | 9 |
| 51202 | 15 | 32 | 12 |
| 51103 | 17 | 30 | 9 |
| 51203 | 17 | 35 | 12 |
| 51104 | 20 | 35 | 10 |
| 51204 | 20 | 40 | 14 |
| 51105 | 25 | 42 | 11 |
| 51205 | 25 | 47 | 15 |
| 51305 | 25 | 52 | 18 |
| 51405 | 25 | 60 | 24 |
| 51106 | 30 | 47 | 11 |
| 51206 | 30 | 52 | 16 |
| 51306 | 30 | 60 | 21 |
| 51406 | 30 | 70 | 28 |
| 51107 | 35 | 52 | 12 |
| 51207 | 35 | 62 | 18 |
| 51307 | 35 | 68 | 24 |
| 51407 | 35 | 80 | 32 |
| 51108 | 40 | 60 | 13 |
| 51208 | 40 | 68 | 19 |
| 51308 | 40 | 78 | 26 |
| 51408 | 40 | 90 | 36 |
| 51109 | 45 | 65 | 14 |
| 51209 | 45 | 73 | 20 |
| 51309 | 45 | 85 | 28 |
| 51409 | 45 | 100 | 39 |
| 51110 | 50 | 70 | 14 |
| 51210 | 50 | 78 | 22 |
| 51310 | 50 | 95 | 31 |
| 51410 | 50 | 110 | 43 |
| 51111 | 55 | 78 | 16 |
| 51211 | 55 | 90 | 25 |
| 51311 | 55 | 105 | 35 |
| 51411 | 55 | 120 | 48 |
| 51112 | 60 |  85 |
17 |
| 51212 | 60 | 95 | 26 |
| 51312 | 60 | 110 | 35 |
| 51412 M | 60 | 130 | 51 |
| 51113 | 65 | 90 | 18 |
| 51213 | 65 | 100 | 27 |
| 51313 | 65 | 115 | 36 |
| 51413 M | 65 | 140 | 56 |
| 51114 | 70 | 95 | 18 |
| 51214 | 70 | 105 | 27 |
| 51314 | 70 | 125 | 40 |
| 51414 M | 70 | 150 | 60 |
| 51115 | 75 | 100 | 19 |
| 51215 | 75 | 110 | 27 |
| 51315 | 75 | 135 | 44 |
| 51415 M | 75 | 160 | 65 |
| 51116 | 80 | 105 | 19 |
| 51216 | 80 | 115 | 28 |
| 51316 | 80 | 140 | 44 |
| 51416 | 80 | 170 | 68 |
| 51416 M | 80 | 170 | 68 |
| 51117 | 85 | 110 | 19 |
| 51217 | 85 | 125 | 31 |
| 51317 | 85 | 150 | 49 |
| 51417 M | 85 | 180 | 72 |
| 51118 | 90 | 120 | 22 |
| 51218 | 90 | 135 | 35 |
| 51318 | 90 | 155 | 50 |
| 51418 M | 90 | 190 | 77 |
| 51120 | 100 | 135 | 25 |
| 51220 | 100 | 150 | 38 |
| 51320 | 100 | 170 | 55 |
| 51420 M | 100 | 210 | 85 |
| 51122 | 110 | 145 | 25 |
| 51222 | 110 | 160 | 38 |
| 51322 M | 110 | 190 | 63 |
| 51124 | 120 | 155 | 25 |
| 51224 | 120 | 170 | 39 |
| 51324 M | 120 | 210 | 70 |
| 51126 | 130 | 170 | 30 |
| 51226 | 130 | 190 | 45 |
| 51326 M | 130 | 225 | 75 |
| 51128 | 140 | 180 | 31 |
| 51228 | 140 | 200 | 46 |
| 51328 M | 140 | 240 | 80 |
| 51130 M | 150 | 190 | 31 |
| 51230 M | 150 | 215 | 50 |
| 51330 M | 150 | 250 | 80 |
| 51132 M | 160 | 200 | 31 |
| 51232 M | 160 | 225 | 51 |
| 51332 M | 160 | 270 | 87 |
| 51134 M | 170 | 215 | 34 |
| 51234 M | 170 | 240 | 55 |
| 51334 M | 170 | 280 | 87 |
| 51136 M | 180 | 225 | 34 |
| 51236 M | 180 | 250 | 56 |
| 51336 M | 180 | 300 | 95 |
| 51138 M | 190 | 240 | 37 |
| 51238 M | 190 | 270 | 62 |
| 51140 M | 200 | 250 | 37 |
| 51240 M | 200 | 280 | 62 |
| 51340 M | 200 | 340 | 110 |
| 51144 M | 220 | 270 | 37 |
| 51244 M | 220 | 300 | 63 |
| 51148 M | 240 | 300 | 45 |
| 51248 M | 240 | 340 | 78 |
| 51152 M | 260 | 320 | 45 |
| 51252 M | 260 | 360 | 79 |
| 51156 M | 280 | 350 | 53 |
| 51256 M | 280 | 380 | 80 |
| 51160 M | 300 | 380 | 62 |
| 51260 M | 300 | 420 | 95 |
| 51164 M | 320 | 400 | 63 |
| 51264 F | 320 | 440 | 95 |
| 51264 M | 320 | 440 | 95 |
| 51168 M | 340 | 420 | 64 |
| 51268 F | 340 | 460 | 96 |
| 51368 F | 340 | 540 | 160 |
| 51172 F | 360 | 440 | 65 |
| 51272 F | 360 | 500 | 110 |
| 59172 F | 360 | 440 | 48 |
| 351793 | 380 | 460 | 36 |
| 51176 F | 380 | 460 | 65 |
| 51276 F | 380 | 520 | 112 |
| 59176 F | 380 | 460 | 48 |
| 51080 F | 400 | 440 | 30 |
| 51180 F | 400 | 480 | 65 |
| 51280 F | 400 | 540 | 112 |
| 59180 F | 400 | 480 | 48 |
| 51084 F | 420 | 460 | 30 |
| 51184 F | 420 | 500 | 65 |
| 51284 F | 420 | 580 | 130 |
| 59184 F | 420 | 500 | 48 |
| 51088 F | 440 | 480 | 30 |
| 51188 F | 440 | 540 | 80 |
| 51288 F | 440 | 600 | 130 |
| 59188 F | 440 | 540 | 60 |
| 51092 F | 460 | 500 | 30 |
| 51192 F | 460 | 560 | 80 |
| 51292 F | 460 | 620 | 130 |
| 59192 F | 460 | 560 | 60 |
| 51096 F | 480 | 520 | 30 |
| 51196 F | 480 | 580 | 80 |
| 51296 F | 480 | 650 | 135 |
| 59196 F | 480 | 580 | 60 |
| 510/500 F | 500 | 540 | 30 |
| 511/500 F | 500 | 600 | 80 |
| 512/500 F | 500 | 670 | 135 |
| 591/500 F | 500 | 600 | 60 |
| 510/530 F | 530 | 580 | 38 |
| 511/530 F | 530 | 640 | 85 |
| 591/530 F | 530 | 640 | 67 |
| 510/560 F | 560 | 610 | 38 |
| 511/560 F | 560 | 670 | 85 |
| 591/560 F | 560 | 670 | 67 |
| 350769 | 600 | 800 | 90 |
| 510/600 F | 600 | 650 | 38 |
| 511/600 F | 600 | 710 | 85 |
| BD1-8000 | 600 | 870 | 118 |
| 510/630 F | 630 | 680 | 38 |
| 511/630 F | 630 | 750 |  95 |
| 591/630 F | 630 | 750 | 73 |
| 511/670 F | 670 | 800 | 105 |
| 511/670 M | 670 | 800 | 105 |
| 591/670 F | 670 | 800 | 78 |
| 510/710 F | 710 | 780 | 53 |
| 511/710 F | 710 | 850 | 112 |
| 510/750 F | 750 | 820 | 53 |
| 511/750 M | 750 | 900 | 120 |
| 591/750 M | 750 | 900 | 90 |
| 510/800 F | 800 | 870 | 53 |
| 591/800 M | 800 | 950 | 90 |
| 510/850 M | 850 | 920 | 53 |
| 511/850 F | 850 | 1000 | 120 |
| 591/850 M | 850 | 1000 | 90 |
| 510/900 M | 900 | 980 | 63 |
| 511/900 F | 900 | 1060 | 130 |
| 511/900 M | 900 | 1060 | 130 |
| 591/900 M | 900 | 1060 | 95 |
| 510/950 M | 950 | 1030 | 63 |
| 511/950 F | 950 | 1120 | 135 |
| 591/950 M | 950 | 1120 | 103 |
| 510/1000 M | 1000 | 1090 | 70 |
| 511/1000 F | 1000 | 1180 | 140 |
| 591/1000 M | 1000 | 1180 | 109 |
| 510/1060 M | 1060 | 1150 | 70 |
| 511/1060 M | 1060 | 1250 | 150 |
| 591/1060 F | 1060 | 1250 | 115 |
| 511/1120 F | 1120 | 1320 | 160 |
| 511/1180 F | 1180 | 1400 | 175 |
| BD1B 351890 A | 1380 | 1535 | 130 |
| 511/1400 F | 1400 | 1630 | 180 |
| 240930 | 60 | 13 |
